Giada F108D Intel N100 1xDDR4 3200 Mhz 2xHDMI

What this part is

<p>The Giada F108D Signage Player adopts Intel® Alder Lake-N processors, giving you good performance while featuring a low-power range from 6-15W. The book-size embedded PC is specially designed for digital signage and kiosk applications. The slim embedded PC supports rich I/O ports, including dual COM ports, 6 USB Type-A and dual LAN ports. It can also be easily integrated into vending machines, self-service and check-in kiosks. The digital signage player also comes with built-in Intel® UHD Graphics. It has a DP and two HDMI ports, supporting resolutions up to 4096 x 2160@60Hz. With a passive thermal cooling system, the fanless design reduces the failure rate and makes the device run noise-free and dustproof.</p> <h3>FEATURES:</h3> <ul> <li>Intel® Processor N100</li> <li>DDR4 3200MHz memory support</li> <li>Intel UHD onboard graphics</li> <li>Up to 4k resolution support</li> <li>1x DP and 2x HDMI output</li> <li>Support for Wi-Fi/Bluetooth module</li> <li>Small form factor design</li> </ul> <h3>SPECIFICATION:</h3> <ul> <li>CPU: Intel® Processor N100 (Fanless)</li> <li>Turbo Frequency: 3.40GHz</li> <li>Chipset: SoC</li> <li>Processing Units: 4 Cores</li> <li>TDP: 6W</li> <li>System Memory: Up to 16 GB, 1 x SO-DIMM DDR4-3200 MHz</li> <li>Storage: 1 x M-Key M.2 (2280) for PCIe3.0 X4 SSD</li> <li>Watchdog Timer: Yes</li> <li>Auto Power On: Yes</li> <li>RTC: Set up independently every day, a week as a cycle</li> <li>Remo on: No</li> <li>Power Requirement: DC-IN, 19 V/2.37 A</li> <li>Construction: Metal</li> <li>Operating System: Windows 11 (64bit) /Linux Ubuntu (64bit)</li> <li>Operating Temperature: 0°C ~45°C (32°F~113°F) @0.7m/s Air Flow</li> <li>Certifications: CE, FCC Class B, UKCA</li> <li>Humidity: 95% @ 45°C (non-condensing</li> <li>Network Controller: 2 x Realtek RTL 8111H Gigabit Ethernet</li> <li>Ethernet Interface: 2 x RJ45</li> <li>Wi-Fi/BT: 1 x E-Key M.2 (2230) for Wi-Fi/BT, Support Wi-Fi 5, Wi-Fi 6</li> <li>Mobile Network: 1 x B-Key M.2 (3042) for 3G/4G, 1 x SIM Slot</li> <li>GPU: Intel® UHD Graphics</li> <li>Graphic Engine: DirectX 12.1, OpenGL 4.6, OpenCL 3.0</li> <li>Display Interface: 1 x DP (Max.4096 x 2160 @60Hz), 2 x HDMI (Max.4096 x 2160 @60Hz)</li> <li>USB: 2 x USB3.2 Gen2, 4 x USB2.0</li> <li>Serial Port: 2 x RS232</li> <li>Audio: 1 x MIC-IN, 1 x AUDIO-OUT</li> <li>Button: 1 x Power on, 1 x CLR-CMOS</li> <li>Antenna: 2 x Connector for Wi-Fi/BT</li> <li>Product Dimensions: 18.9 x 14.8 x 2.6 cm</li> </ul> <h3>WHAT'S IN THE BOX:</h3> <ul> <li>Giada F108D Alder Lake-N Book Size Signage Player - Black x1</li> </ul>
